1953-62 Arrow DECALS, INSTRUCTIONS & LABELS Arrow Radiator & Cooling System

Radiator & Cooling System

Diagrams:


Radiator Plate Diagram Thumbnail
Radiator Plate
(click to enlarge)


A2029A202953-61ID PLATE - "Harrison" brass radiator (up to VIN #1700, 1961) (specify year & date), 1957 #3141674, 1958M-61 #313368949.95
 A2029S58EID PLATE - 3139588 early 1958 only-specify month/custom made139.95
A2346A234662LID PLATE - "Harrison" radiator, second design, metal, (not date stamped)27.60
A2344A234460-62EID PLATE/METAL -"Harrison", aluminum radiator, w/part # & date (specify when ordering)38.64
A2416A241660-62EID PLATE/METAL -"Harrison", w/o part # or date18.95
A2347A234760-62SCREW SET - metal radiator tag (pr)2.20
A2336A233655-62STICKER - 55-57 "Caution" on RH side of radiator left of filler neck, 61-62 "Caution" on expansion tank, on inner fender, side of the expansion tank under the radiator cap 3.15
A2338A233858-62STICKER - "Caution" on brass radiator top, just right of center3.70
